Inch and Metric Threading

12″ 3 Jaw Chuck

Aloris Tool Post

Swing over bed

20"

Swing over cross slide

10-1/2"

Distance between centers

60"

Hole through spindle

4-1/4"

Spindle speeds (#)

(12) 35-1500 RPM

Metric feeds (#)

(16) 0.03 – 0.76

Inch feeds (#)

(16) 0.0012 – 0.0299

Metric threads (#)

(19) 0.5 – 7

Module Threads (#)

(13) 0.25 – 3.5

Whitworth Threads (#)

(28) 4 – 56

Diametral threads (#)

(28) 8 – 112

Cross slide travel

13-1/4"

Compound slide travel

6-1/2"

Leadscrew diameter x thread pitch

1-1/4" x 4 TPI

Bed width

13"

Tailstock quill travel

7-3/4"

Tailstock quill taper

#5 MT

Tailstock quill diameter

2-5/8"

Volts

220 / 440

Phase

3

Cycles

60

Approximate dimensions

118" x 35" x 50" high

Approximate weight

5,500 lbs.
