CNC backguage

Pendant arm control

Ram tilt control

Pedestal control with foot pedal

Flush floor design

Tonnage — 175

Overall length of bed and ram — 144”

Distance between housings —124”

Capacity —10’ x 1/4”

Open height — 14”

Closed height — 6”

Throat — 10”

Bed height x width — 34” x 8”

Ram stroke — 8”

Approach speed — 80" / minute

Pressing speed — 17" / minute

Return speed — 180" / minute

Main motor — 20 HP

Volts — 575

Phase - 3

Cycles — 60

Amps — 21

Approximate dimensions — 178" x 66" x 94" high

Approximate weight — 24,000 lbs.

This 175 ton Accurpress CNC press brake has a bending capacity of 10’ x 1/4” using a die with a 2” wide opening. It is equipped with a CNC back gauge, pendant arm control, ram tilt control and pedestal control stand with a foot pedal.

For questions or to schedule an inspection of this 175 ton Accurpress CNC press brake, please call 515-999-2999 or email your request to sales@nsmachine.com. To request a quote for this 175 ton Accurpress CNC press brake, use the “Request Quote” button on this page.
