9-1/2″ hole through spindle

24″ 3-jaw chuck

Bar stock support (rear)

4-way toolpost

Threading

Coolant system

Work light

Swing over bedways

40"

Swing over carriage wing

37-1/2"

Swing over cross slide carriage

33-1/2"

Distance between centers

93"

Spindle bore diameter

9-1/2"

Spindle nose

A1-20

Range of spindle speeds

11 to 280 RPM

Chuck size

24" (3-jaw)

Cross slide travel of tool post carriage

18"

Longitudinal carriage travel

93"

Power cross feeds

(16) .005" – .044"

Power longitudinal feeds

(16) .005" – .044"

Longitudinal travel of turret carriage

93"

End of spindle to face of turret

103"

Motor

40 HP / 1760 RPM

Volts

220 / 440

Phase

3

Cycles

60

Amps

100/50

Coolant pump motor

1/2 HP

Approximate dimensions

198" x 86" x 75" high

Approximate weight

24,000 lbs.
