Manufacturer: Scotchman

Model Number: DO-8514-20M

Serial Number: 1097M1107

Model Year: 2007 (Price new is $38,390)

Size / Capacity: 85 ton punch, 6″ x 6″ x 1/2″ angle

Stock Number: 13577

NEW in 2007 – Original paint

Dual operator machine

5 work stations

2 foot pedal controls

72″ wide extended punch table

33″ back stop for angle and section shears

* Brake & pipe notching attachments not included

Punch tonnage

85

Punch capacity

1-1/16" in 1"

Punch throat depth

14"

Strokes per minute, 1/4” stroke

48 SPM

Strokes per minute, 3/4” stroke

20 SPM

Flat bar shearing length

20"

Flat bar shear capacity

1" x 16" to 3/4" x 20"

Angle shear capacity at 90 degrees

6" x 6" x 1/2"

Angle shear capacity at 45 degrees

4" x 4" x 1/2"

12" Brake

*85 ton

24" Brake

*85 ton

Open end brake

*5" x 5/8"

Pipe notcher, schedule 40 ID

* 3/4", 1", 1-1/4", 1-1/2", 2"

Rectangular notcher

2" x 4" x 1.2"

90 degree V notcher (notcher station)

3" x 3" x 1/2"

Channel shear

2" to 6"

Round rod

1/2" to 1-1/2"

Square rod

1-1/2" max.

Hydraulic pressure

3,350 / 3,800 psi

Motor

10 HP

Volts

230 / 460

Phase

3

Cycles

60

Approximate dimensions

79" x 30" x 73" high

Approximate weight

5,500 lbs.
