2007 1/4″ x 12′ Primeline Hydraulic Shear | 3760X6
sold
-
Manufacturer: Primeline
Model Number: 3760X6
Serial Number: 12673
Model Year: 2007
Size / Capacity: 1/4″ x 12′
Stock Number: 13438
-
30″ front operated power back gauge
Elgo programmable back gauge control
Side squaring arm
(3) front sheet support arms
Foot pedal control stand w/emergency stop
Finger guard
Manual blade gap adjustment
-
Shearing length
146.45 (3720 mm)
Shearing capacity
0.24 (6 mm)
Rake angle
1.8°
Number of holddowns
20
Strokes per minute
9
System pressure
410 lbs/sq.ft. (200 kg/cm2)
Pump flow rate
14.17 cu in/rev (36 cm3/rev)
Oil tank volume
42.3 gallons (160 lt)
Back gauge range
29.53" (750 mm)
Motor
4.3 HP (3.2 KW)
Volts
230 / 460
Phase
3
Cycles
60 Hz
Amps
32/16
Approximate dimensions
178" x 78" x 71"high
Approximate weight
16,314 lbs (7400 kg)
