Hydraulically driven top roll

Hydraulically driven bottom pinch roll

Hydraulic adjustment of bottom rolls

Hydraulic drop end

Wire-drawn encoders with digital readouts

Hand held pendant control

(*) .375″ x 10′ to an 18.5″ minimum I.D. and larger diameters of materials having an 85,000 PSI maximum tensile and 56,000 PSI maximum yield.

(**) .438 x 10′ to a 16″ minimum I.D. of mild steel materials having 60,000 PSI maximum tensile and 40,000 maximum yield to large or boiler diameters.

Length of rolls

122"

Bending capacity

3/8" x 10' (*)

Bending capacity, mild steel

7/16" x 10' (**)

Diameter of top & lower rolls

10"

Diameter of pinch roll

9"

Rolling speed

14 FPM

Roll hardness

32 RC

Motor

15 HP / 1760 RPM

Volts

230 / 460

Phase

3

Cycles

60

Amps

38.4 / 19.2

Approximate dimensions

188" x 63" x 73" high

Approximate weight

20,000 lbs.
