2-Axis CNC pendant arm control

Sick C4000 light curtains

Powered crowning on bed

Control stand with palm buttons & dual foot pedal controls

Optional:
8-way die (157-11/16")
90 degree punch (156-5/8")
90 degree vee die, 2-3/4" opening (158")

Tonnage — 200

Length of bed and ram — 157.4”

Distance between housings — 121.5”

Throat depth — 12.5”

Stroke adjustment of ram — 2.75”

Ram travel — 7.0”

Open height — 17.5”

Rapid ram travel speed — 2.4" / second

Rapid ram return speed — 2.0" / second

Backgauge travel — 24”

Hydraulic oil capacity — 97 gallons

Motor — 20 HP

Volts 220/440

Phase — 3

Cycles - 60

Approximate dimensions — 180" x 69" x 104.5" high

Approximate weight — 28,000 lbs

The US Industrial US20013MC is a 200 ton press brake capable of bending 1/4” x 13’ mild steel using a standard 2” opening die. The 2-axis CNC backgauge provides the operator with the ability to program bending operations for efficiency and accuracy. Sick 4000 light curtains ensure the safety of operators. Optional full length tooling is also available including an 8-way die, a single vee die with a 2-3/4” opening and a 90 degree punch.

For questions or to schedule an inspection of this 200 ton US Industrial CNC Press Brake, please call 515-999-2999 or email your request to sales@nsmachine.com. To request a quote for this 200 ton US Industrial CNC Press Brake, use the “Request Quote” button on this page.
