Power clamping

Power elevation

Coolant pump

Diameter of column

12-5/8"

Column surface to spindle center, max.

49-3/8"

Column surface to spindle center, min.

11-5/8"

Spindle speeds (24)

32 to 1985 RPM

Feeds (6)

.003 to .039

Spindle taper

MT #5

Diameter of spindle

2-3/8"

Diameter of quill

3-1/16"

Vertical travel of spindle

11-13/16"

Horizontal travel of spindle head

37-3/4"

Vertical travel of arm

25-5/8"

Base to spindle, maximum

51-3/4"

Base to spindle, minimum

13"

Drilling capacity, steel

2-1/4"

Drilling capacity, cast

2-5/8"

Motor

5 HP / 1730 RPM

Volts

220 / 440

Phase

3

Hz

60

Amps

13.4 / 6.7

Approximate dimensions

75" x 35" x 85" high

Approximate weight

6,100 lbs.
