Collet closer

Set of 5C collets

Collet holder

Taper attachment

Chuck guard

Quick change tool post & 1 holder

Swing over bedways

12"

Swing over cross slide

7"

Distance between centers

36"

Diamter of hole through spindle

1-7/16"

Spindle speeds

52 to 2000 RPM

Threads (54)

4 to 192 TPI

Feeds, longitudinal (54)

.0367 to .00076

Bed width

7-3/8"

Leadscrew diamter

1"

Leadscrew pitch

8 TPI

Motor

2 HP

Motor speed

1800/1500

Volts

220/440

Phase

3

Cycles

60/50

Amps @ 60 cycle

6.4 / 3.2

Amps @ 50 cycle

7.6 / 3.8

Approximate dimensions

73" x 30" x 51" high

Approximate weight

2,100 lbs.
