- High precision cartridge type spindle equipped with 4 pieces of class 7 angular contact ball bearings, suitable for heavy duty grinding

- 3-Axis fully automatic with surface and plunge grinding cycles

- Separate hydraulic system prevents vibration and reduces heat transference

- Saddle travels on Turcite-B coated and hand scraped double V guideways

- Meehanite cast iron

- Wheel head rises up automatically and table parks at left or right side after cycle is completed

Table Working Surface: 12" x 24"

Grinding Width Capacity, Maximum: 12"

Grinding Length Capacity, Maximum: 24"

Height Spindle Centerline To Table, Max: 24.75"

Grinding Wheel Diameter, Standard: 14"

Grinding Wheel Width, Standard: 2"

Grinding Wheel Hole Diameter: 5"

Table Longitudinal Travel Hydraulic: 25.37"

Table Longitudinal Travel Manual: 27.5"

Table Cross Travel, Automatic: 14.17"

Table Cross Travel, Manual: 14.5"

Table speed: 16 to 82 FPM

Table Cross In-Feeds, Range: 0.125 to 2 IPR

Cross Rapid Travel, Approx.: 56 IPM

Spindle Vertical Feeds, Automatic: 0.0001 to .002 IPR

Power Rapid Vertical Traverse: 13 IPM

Grinding Wheel Spindle Motor: 5 HP

Hydraulic Drive Motor: 2 HP

Cross Feed Drive Motor: 1/2 HP

Elevating Drive Motor: 1/4 HP

Coolant Pump Motor: 1/8 HP

Approximate Dimensions: 106" x 70" x 91" high

Approximate weight: 4,630 lbs

This 12” x 24” Chevalier FSG-3A1224H Hydraulic Surface Grinder is a 3-axis fully automatic grinder.
