Equipped with:

Manual guide roll adjustment

Adjustable guide rolls

Hydraulic adjustment of upper roll

Horizontal or vertical use possible

Push button controls

Diameter of rolls

9-13/16"

Bending rolls speed

10.2 RPM

Rolling speed

26 FPM

Max. bending force

24,200

Capacities

–

...angles, max. (leg out)

3" x 3" x 5/16" – 28" dia.

...angles, min. (leg out)

1" x 1" x 1/4" – 14" dia.

...angles, max. (leg in)

2.5" x 2.5" x 5/16" – 40" dia.

...angles, min. (leg in)

1" x 1" x 1/4" – 14" dia.

...tees, max. (leg out)

4" x 3" x 3/8" – 23" dia.

...tees, min. (leg out)

3/4" x 3/4" x 1/8" – 14" dia.

...tees, max. (leg in)

4" x 3" x 3/8" – 34" dia.

...tees, min. (leg in)

3/4" x 3/4" x 1/8" – 14" dia.

...flats, max.

5" x 3/4" – 16" dia.

...squares, max.

1-3/4" x 1-3/4" – 16" dia.

...rounds, max.

2" solid bar- 16" dia.

...tubing, max.

3" / 2.704" – 30" dia.

...tubing, min.

3/4" – 12" dia.

...I-beam, max.

4" x 2-5/8" – 40" dia.

...channel, max. (leg out/leg in)

5" x 1-3/4" – 32" dia.

Main motor

5.5 HP

Hydraulic motor

2.4 HP

Approx. weight

3,770 lbs

Approx. dimensions

40" x 44" x 50"
